This professional biological microscope is designed for teaching demonstrations, clinical examinations and laboratory applications. great for studying fixed or live cells, hair follicles, bacteria, plants and soil, or water samples

Product Introduction

Specification

Professional Biological Microscope

1. Optical System: Finity optical system
2.Eyepiece PL10X/22mm high eyepoint eyepiece, diopter adjustment ±5, tubeΦ30mm
3.Objective 45mm DIN achromatic objective：4X,10X,40X(S),100X(S,Oil)
4. Viewing Head: Articulated Free Binocular Head, 30°inclined, Interpupillary Distance 50-75mm
5. Nosepiece:Backward quintuple or quadruple objective nosepiece
6.Stage:220X148mm X-axis low hand position double mechanical stage(steel wire transmission),76X50mm,presion 0.1mm,damped double slide clamp
7. Condenser Abbe condenser set
8. Focusing System Coaxial coarse and fine focus knobs, precision 0.002mm
9. Illumination 3W LED lamp with Kohler illumination system

Optional
1.Insert phase contrast apparatus
2.Dry darkfield condenser, Oil-darkfield condenser
3. Polarizing Device
4. Plan objective set,Infinity plan achromatic objective set
5.Swing Abbe condenser
6.5W LED light

Packaging List

1* Storage foam box;
1* Binocular Microscope;
4*195 Objectives, 4X,10X, 40X, 100X;
1* cedar oils;
2*PL10X/22mm Eyepieces;
1* Dust Cover;
1* USB Cable;
1* power adapter;

1pcs/carton

Size:36X31X67cm
G.W:9KGS N.W.:7KGS
