Specification
|
Model |
20-60X80 |
|
Magnification |
20-60X |
|
Objective Diameter(mm) |
80mm |
|
Type of Prism |
BAK4 |
|
Lens Coating |
FMC |
|
Focus System |
Center |
|
Number of lenses |
6 Pieces /4 Groups |
|
Exit Pupil Diameter(mm) |
4-1.33mm |
|
Exit Pupil Distance(mm) |
21-17mm |
|
Angle of View |
2-1° |
|
Field of View |
105–52.5ft/1000yds, 35-17.5m/1000m |
|
Close Focus |
6m |
|
Waterproof |
Yes |
|
Eyepiece Cups |
Twist Up |
|
Body Material |
ABS |
|
Unit Weight |
1450g |
|
Unit Dimension |
450X190X105mm |
Why do we choose BAK4 Spotting Scope ?
1.Refraction Index: BAK4 glass has a higher refractive index compared to BK7 glass, which means it bends light more efficiently. This results in sharper and brighter images with higher contrast.
2.Reduced Internal Reflection: BAK4 glass minimizes internal light scattering and reflection, leading to clearer and more detailed images. This is crucial for spotting scopes used in various outdoor conditions where light conditions may vary.
3.Edge-to-Edge Clarity: Spotting scopes utilizing BAK4 prisms often provide better edge-to-edge clarity, ensuring that the entire field of view remains sharp and distortion-free.
How to choose BAK4 Spotting Scope ?
1.Magnification Range:
Spotting scopes typically offer a range of magnifications, such as 20-60x or 15-45x. Higher magnification allows you to zoom in on distant objects for detailed observation. However, keep in mind that higher magnification also amplifies vibrations and atmospheric distortions, so it may not always be practical, especially in windy conditions or over long distances.
2.Prism Type:
BAK4 prisms are preferred over BK7 prisms due to their superior optical properties. BAK4 prisms have a higher refractive index and less internal light scattering, which translates to better image quality with improved resolution, contrast, and brightness, especially at the edges of the field of view.
3.Eye Relief:
Eye relief is the distance between the eyepiece and your eye when you can still see the entire field of view without experiencing blackouts or vignetting. If you wear glasses, choose a spotting scope with sufficient eye relief to accommodate them comfortably without having to remove them for viewing.
